Model HELIOS-500 is a compact, effective, affordable and lightweight UV Ozone Cleaning system, taking minimal lab and clean room space.


The HELIOS-500 UV Ozone Cleaner has an affordable price and we provide free shipping in USA. Complete the quick form below to receive a formal quote today.


The UV Ozone Cleaner is equipped with  digital process timer, High-intensity UV (Ultraviolet) grid lamp for increased uniformity, hour counter, exhaust port and LED indicator lights.

The HELIOS UV Ozone Cleaner is designed to remove molecular levels of organic contamination to achieve the cleanest possible surfaces on various types of substrates. A high intensity mercury vapor UV grid lamp generates 254nm ultraviolet radiation which breaks the bonds of organic molecules on the surface. Strong emission at 185nm converts atmospheric oxygen into reactive ozone, which attacks the small molecular fragments and creates volatile organics.

This compact tabletop UV-Ozone Cleaner features a drawer-loaded sample stage which can process up to 5.7” (W) x 5.7“ (D) x 1.4” (H) substrates and boosts UV and ozone production using a custom synthetic quartz UV Grid lamp. Operation is as simple as placing your samples in the process chamber, closing the drawer, and setting the desired process time on the digital timer. This system features a drawer safety interlock switch to protect users from UV and ozone exposure during the cleaning process.

The HELIOS-500 model features UV Grid lamp for greater ozone production, more uniform UV radiation and faster cleaning rates.

We provide the most competitive prices including free U.S. shipping. This system can usually ship within 2-3 days after receipt of order.

  • Maximum sample height: 1.4″ (35mm)
  • UV exposure area: 5.7” x 5.7” (145mm x 145mm)
  • Weight: 12 lbs.
  • System dimensions: 7.75″ x 8.37″ x 7″ (WxDxH) – 197 x 212 x 178 mm


  • Can process up to 5.7” x 5.7“ x 1.4” (WxDxH) substrates
  • Maximum sample height of 1.4″ (35 mm)
  • Stainless steel pedestal for positioning versatility (1″ or 25.4 mm height)
  • UV grid lamp with a 5″x5″ reflector
  • Drawer safety interlock
  • LED process indicator lights
  • Digital process timer (seconds, minutes or hours)
  • Compact footprint: 7.8” x 8.4” x 7” (WxDxH)
  • Lightweight, rugged design: 12 lbs.
  • Electrical: 110VAC, 60Hz
  • Low cost of ownership and operation
  • Room temperature, atmospheric pressure process
  • 1-inch OD stainless steel exhaust port
  • Safer than piranha solution
  • Fast and simple operation


  • Cleaning Silicon and Silicon Nitride AFM/SPM Probes
  • Ultraviolet Curing of UV-adhesives
  • UV photo-patterning of SAM surfaces
  • Cleaning Surface Plasmon Resonance (SPR) chips
  • Cleaning Quartz Crystal Micro-balance (QCM) sensors
  • Wafer Cleaning
  • Surface Oxidation and Preparation
  • Improving Surface Hydrophilicity
  • Surface Cleaning
  • Preparation for Thin Film Deposition
  • Surface Patterning and Sterilization
  • Cleaning Lenses and Optics
  • Bonding and oxidizing PDMS
  • Cleaning MEMS and Glass Devices
